Reference intervals – and what Sysmex can offer

For any clinical laboratory analysis, reliable and accurate reference intervals are essential to correctly interpret the test results. Accordingly, Sysmex is very frequently asked about reference intervals for haematology parameters.

While we are glad to provide you with a selection of literature, we would like to point out that reference intervals from different studies are only conditionally transferable, depending on the age, gender, ethnicity, etc. of the patient population in question. For this reason, the individuals who served as the basis for the selected reference interval should be as similar as possible to the patient population to whom the reference interval is to be applied.

Currently, there are several scientific publications available that provide information about reference intervals for Sysmex analysers. These studies were performed on a variety of Sysmex haematology analyser models and the reference intervals evidently differ according to the populations involved. This also means that published reference intervals from older analyser models have to be validated before they may be used with newer ones. Since – as explained above – there are differences between haematological reference intervals determined from different populations, the information in the table below may facilitate the selection of an appropriate reference interval as an initial point for validation.

Examples of reference intervals for Sysmex analysers

First author






Bildirici A et al. 2023 Turk J Biochem XN-1000 CBC+DIFF Turkish, adult
Mrosewski I et al. 2023 Clin Chem Lab Med XN-9000 DIFF German, paediatric
L van Pelt JL et al. 2022 Clin Chem Lab Med XN-Series CBC+DIFF+RET+PLT-F Dutch
Dockree S et al. 2021 EBioMedicine XN-Series WBC+DIFF British, pregnant women (antenatal and postnatal)
Ianni B et al. 2021 Arch Pathol Lab Med XN-1000 CBC+DIFF+RET+PLT-F US American, newborns
Mrosewski I et al. 2021 Clin Chem Lab Med XN-9000 CBC German, paediatric
Song MY et al. 2021 Int J Lab Hematol XN-20, XN-350, XS-800i CBC + DIFF Chinese, paediatric
Wilson S et al. 2021 Int J Lab Hematol XN-3000 CBC+DIFF Canadian, paediatric
Bohn MK et al. 2020 Int J Lab Hematol XN-3000 CBC+DIFF Canadian, paediatric
Florin L et al. 2020 Int J Lab Hematol XN-Series CBC+DIFF+RET Belgium, adult
Zierk J et al. 2019 Clin Chem Lab Med XN-Series CBC German, paediatric
Arbiol-Roca A et al. 2018 EJIFCC XN-Series CBC+DIFF+RET Spanish

Validation of reference intervals

Adopting a published reference interval without validation is not permissible and can even be dangerous for patients. Its suitability as a reference must be examined in every case. To do this, the International Federation of Clinical Chemistry (IFCC) suggests the following procedure [1]:

Twenty local reference samples are taken and compared with the reference interval published elsewhere. If not more than two of the 20 samples are outside this interval, it may be used.  If three to four samples are outside the reference interval, a further 20 new samples must be taken and measured. If not more than two of these 20 samples are outside the interval, it may be used. If in the initial verification five or more samples or more than two of a repeated set of samples are outside the published interval, it is not suitable for use as a reference for local patients. A new survey or the validation of another, different reference interval would be the next options.

[1] Solberg HE et al. (2004): The IFCC recommendation on estimation of reference intervals. The RefVal program. Clin Chem Lab Med 42: 710–714.

A new indirect approach of determining reference intervals

The International Federation of Clinical Chemistry (IFCC) Committee on Reference Intervals and Decision Limits (C-RIDL) recently published an opinion paper about ‘indirect’ methods for reference interval determination [2]. The ‘indirect’ approach to determine reference intervals refers to a statistical analysis of already existing results from specimens which were collected for routine purposes (for example, samples collected for screening, diagnostic or monitoring purposes). This novel approach is not only a useful adjunct to the use of traditional direct methods, but also has a number of advantages such as basing the outcomes on the analytical and pre-analytical procedures in use, the ability to address a wide interval of populations, especially the population served by the laboratory, and, importantly, the relative ease of use and far lower costs. In this opinion paper, the IFCC C-RIDL encourages laboratories ‘to use indirect methods to evaluate their reference intervals in use, to estimate new reference intervals and to publish and share their results in appropriate detail and also to continue the search for new and improved techniques for the process’.

[2] Jones GRD et al. (2018): Indirect methods for reference interval determination – review and recommendations. CCLM, 57 (1), 20-29 Free online:

SEED: Reference intervals – and what Sysmex can offer

To define whether a patient’s results are considered ‘normal’ or ‘healthy’ reference intervals are needed. In this article the prerequisites for reference intervals and different approaches for determination of those are described. Sysmex provides a list of scientific publications that inform about the reference intervals for Sysmex analysers, which can be found in this article.

SEED: The art of defining reference intervals

To interpret the result of a blood count, a physician needs reference intervals from healthy people alongside the results of the analysis. The challenge is to define a ’healthy’ reference cohort. Common diseases with a long latency period, such as anaemia, are not recognised by individuals and therefore cannot be determined via questionnaires. The LAVE approach, explained in detail in the SEED, offers the possibility to exclude exactly these individuals from the reference cohort. The SEED lists reference intervals for adults for 105 parameters of XN-Series analysers based on a Dutch cohort.
